Specifi cations
PLD4.2 PLD4.3 PLD4.5
4 Ch. Continuous
1
8
4
2
400 Watts
400 Watts
325 Watts
625 Watts
625 Watts
625 Watts
1150 Watts
1250 Watts
625 Watts
2 Ch. Continuous
1
8
4
2
800 Watts
800 Watts
650 Watts
1250 Watts
1200 Watts
1200 Watts
2250 Watts
2250 Watts
2100 Watts
1 Ch. Continuous
1
8
4
2
1
1600 Watts
1600 Watts
1600 Watts
1600 Watts
2500 Watts
2500 Watts
2500 Watts
2500 Watts
4200 Watts
4200 Watts
4250 Watts
3700 Watts
Typical Distortion
8
4
0.01 - 0.03%
0.03 - 0.06%
0.01 - 0.03%
0.03 - 0.06%
0.01 - 0.03%
0.03 - 0.06%
Maximum Distortion
4 - 8 1.0% 1.0% 1.0%
Frequency response (8) 20 Hz - 15 kHz +/- 0.2 dB
20 Hz - 20 kHz +0.2 dB / -0.7 dB
20 Hz - 15 kHz +/- 0.2 dB
20 Hz - 20 kHz +0.2 dB / -0.7 dB
20 Hz - 15 kHz +/- 0.2 dB
20 Hz - 20 kHz +0.2 dB / -0.7 dB
Noise
Unweighted Output Unmuted
Weighted Output Muted
-101 dB
-109 dB
-101 dB
-109 dB
-101 dB
-109 dB
Gain (1.2V setting) 34.0 dB 38.4 dB 38.4 dB
Damping factor >150 >150 >150
Input impedance >10k, balanced or unbalanced >10k, balanced or unbalanced >10k, balanced or unbalanced
Maximum input level
(3.9V setting)
(1.2V setting)
12.28V (+24 dBu)
3.88V (+14 dBu)
12.28V (+24 dBu)
3.88V (+14 dBu)
12.28V (+24 dBu)
3.88V (+14 dBu)
Controls and indicators (front) Power • Channel MUTE Buttons • Channel SELECT Buttons • Channel Input Signal and CLIP LED Indicators • Channel Output and
LIMIT LED Meters • HOME, ENTER, EXIT, GAIN Navigation Buttons • Control Knob
Controls and indicators (rear) AC Power Disconnect AC Power Disconnect AC Power Disconnect
Input connectors Female XLR Female XLR Female XLR
Output connectors NL4 NL4 NL4
Amplifi er and load protection Short circuit, open circuit, thermal, RF protection. On/Off muting, DC fault shutdown, active inrush limiting, input current limiting
AC Power Input Universal Power Supply 100 - 240 VAC, 50 - 60 Hz
Dimensions (HWD) 3.5” x 19” x 12” (89 x 482 x 305 mm) 3.5” x 19” x 16” (89 x 482 x 406 mm) 3.5” x 19” x 16” (89 x 482mm x 406mm)
Weight, Net / Shipping 18.5 lb (8.4 kg) / 22 lb (10.0 kg) 21.0 lb (9.5 kg) / 25 lb (11.3 kg) 22.0 lb (10.0 kg) / 26 lb (11.8 kg)
1 - 1.0 kHz sine wave, 1% THD, 1 channel driven
