Passenger’s Side Exterior 110-Volt Plug
Located on the passenger side rear behind the rear wheel well, this plug will only function if power
is supplied through the generator or shore power.
Passenger’s Side Exterior Porch Light
Located behind the passenger side kitchen window, this light is controlled by the switch on the
kitchen end gable near the entrance handle.
Coach & Chassis Batteries:
The chassis battery is located under the hood of the vehicle, supplied by Ford. The coach or
auxiliary battery is an Interstate SRM 24 series deep cycle battery. This battery operates the Motor
Home portion of your vehicle. The coach battery is located on the passenger side in front of the
rear wheel well. It is installed on a slide out battery tray.
