Plockmatic 306 - Connecting Model 306;310 to SR85 with Cover Feeder

(5)
T09149
Communication
cable between the
copier finisher and
the cover feeder.
Communication
cable between the
cover feeder and
the booklet maker.
Install the Model 306/310 to SR85 with fover feeder.
1. Switch off the main power switch.
2. Disconnect the communication cable (2) between the copier
finisher and the cover feeder.
3. Disconnect the communication cabel (1) from the SR85. It is not
necessary to disconnect the connector from the cover feeder.
4. Roll the SR85 off the rails and place the SR85 against the Model
306/310.
5. Mount the communication cable (3) between Model 306/310 and
SR85.
6. Switch on the main power switch.
3
5
12
