Plockmatic 310+ - Collator Components and Controls; Collator Main Components Identification

T10137 Jan 2003
Collator Series 300/400 Operator Manual 3-1
3. Getting to know the collator
3.1 Main components
1 Control panel
2 Adjustable side guide (in each bin)
3 Load lever
4 Power switch
5 Adjustable stacker guide (left)
6 Adjustable stacker guide (front)
7 Bin extension plate
8 Power cord receptacle
9 Third party receptacle
10 Conveyor door
1
2
3
4
5 6
7
8
9
10
