Plott Cubit - Specifications; Range Specification; Measuring Accuracy; Laser Class and Type

Under favorable conditions (good target surface,room temperature) up to 10 m (33 ft.). under unfavorable
conditions such as bright sunlight, a very weakly reflecting target surface or large temperature fluctuations,the
error can increase by ± 0.25 mm/m (± 0.003 in/ft.) for distances over 10 m (33 ft.).
*
Range
0.3 m to 20 m (0.99ft to 65 ft.)
(Two-directions)
Measure direction
X/Y(Two-directions) 0.5<1 mW
Measuring accuracy (± 3.0 mm≤10m)
Typ.: ± 3.0 mm*
Smallest unit displayed
1 mm (5/128’’) (Two-directions)
Laser class
2
Laser type
620-690 nm, Power<1 mW
Laser / Backlight automatic switch-off
After 30 s
After 90 s
Battery life (built-in)
300 - Cycle capacity of the remaining 80%,
Li-ion 1500 mAh
Dimension (h x d x w)
100.84 x 36 x 91.78 mm
Weight
175.6 g
Storage temperature range
-4-158F (-20~70°)
Operating temperature
32-104F (-0~40°)
Specifications
