7
Installation
7.3 Platform Frame “Horizontal” Adjustment Procedure
Access™ EA & Access™ EAB
1. Undo locking nut "A" until adjustment screw "B" is free to move.
To increase the distance "C" (platform end to ground) turn the adjustment
screw "B" clockwise.
To decrease the distance "C" (platform end to ground) turn the adjustment
screw "B" anti-clockwise
2. Turn the adjustment screw "B" until the platform angle 92° is achieved.
3. The locking nut "A" MUST be re-tightened after any adjustment.
4. Lower the lift and ensure that the Roll Off Ramp Landing Roller "E"
and the Roll Off Ramp "D" are in contact with the floor.
If not repeat the above procedure until correct.
Note: If the L/H & R/H bolts are not equally adjusted/set, the platform may have a side to side
twist.
