TO INCREASE THE DISTANCE "C" (PLATFORM END TO
GROUND) TURN THE ADJUSTMENT SCREW "B" CLOCKWISE
"C"
TO DECREASE THE DISTANCE "C" (PLATFORM END TO
GROUND) TURN THE ADJUSTMENT SCREW "B"
ANTI-CLOCKWISE
PLATFORM SUPPORT ARM
STOW LINKAGE
(SHOWN HIDDEN FOR CLARITY)
92°
"FACTORY" ANGLE (THIS MAY NEED TO BE ADJUSTED)
TO ACHIEVE NO. 4 IN PROCEDURE.
AFTER FITMENT TO VEHICLE.
PLATFORM FRAME
A
B
FLOOR LEVEL
FLOOR LEVEL
E
D
7
Installation
