PLS Access EA Series - Lubrication Schedule and Diagram

Service &
Maintenance
10.7 Weekly Lubrication Access™ EA & Access™ EAB
Bridge Plate Linkage (Lower)
A
Arm Pivots
A
Platform Pivot
Roll-Off Ramp Pivots
TYPE
LUBRICATION SPECIFICATION
Bridge Plate Linkage (Upper)
ACF-50
All Other Springs
1
2
3
4
7
REF. DESCRIPTION
TYPE
6
Platform Hinges
A
A
A
B
A
Stow Linkage (Upper)
5
A
Platform Knuckle
8
A
A
Stow Linkage (Lower)
9
A
Bridge Plate Hinge
10
A
Handrail Pivot
11
A
LITHIUM GREASE EP 2
B
FREQUENCY
Lubrication Diagram
*Lift MUST be cleaned, lubricated and maintained
in accordance with current LOLER regulations
Weekly =
Monthly
=
4
1
7
8
2
6
5
3
3
9
10
11
8
