As described in the previous section, individual overhead panel
components can be isolated and brought to view together with the main
panel view.
• Right-click click-spot 1 to open the overhead panel window
• Locate the overhead panel component you want to isolate
• Right-click on the top-left corner of this component
• The overhead panel will close and only the selected component will
display on the top of the screen
• When done, left click on the top-left corner of the component to
close it, or right-click to bring back the full overhead panel.
Systems Displays and Overhead Panel Components:
Left-clicking on click-spot 2 will open at the same time three windows:
• the Systems Display Control Panel (SDCP),
• the Systems Display (SD) unit,
• the overhead panel component that is related to the selected page
of the SD (if any)
The default SD page on power up is Secondary Engine Parameters
page which has no associated overhead panel component, so the first
time only the SDCP and the SD (displaying the Secondary Engines
page) windows will open.
The SDCP has several cue buttons that are used to select the page to
be displayed on the SD. Pressing one of them will change the page
displayed on the SD and at the same time it will open any overhead
panel component that might be associated with the selected system.
For example if you press the FUEL cue button the FUEL page will
display on the SD and the fuel overhead panel component will open.
Clicking on click-spot 2 while any SDCP, SD or overhead component
windows are open will close all these windows.
