3 User manual
English
Basic features
• WiFi, LAN and AP mode connection.
• Recording on micro SD card, max. 128Gb (card not included).
• To way audio communication, built-in microphone and speaker.
• Outdoor installation, IP66 protection class, ABS housing.
• 8 IR LEDs and 8 white LEDs for visibility at a distance of up
to 20 m.
• P2P connection.
• Remote control through the CamHi Pro application (Android/
iOS) and through the HiP2P application (PC Windows)
• PTZ control from the application.
Technical specifications
Sensor 1/3” GC4653 CMOS
Sensor resolution 4MP
Registration resolution
mainstream 2560 x 1440
substream 800 x 448 / 1-16 fps
Preview resolution 4MP
Video compression H.265
Audio compression AMR/G.711A
Night vision
Colour: 0.1Lux @(F1.2,AGC ON);
0 Lux with IR, B/W 0.01 Lux @
(F1.2,AGC ON),0 Lux with IR
Lens 3.6mm @ F1.8
Viewing angle 80°
Ethernet RJ45 10/100 Mbps
WiFI frequency 2.4 GHz
WiFi transmission power 100mW
