1514
Fixed shaft
Levelling feet
Locking nut
Adjusting nut
Wrench
Not level
Left Right
(The picture above is only for reference. The actual configuration will depend
on the physical product.)
When the fridge door is low:
Open the door, use a wrench to loosen the locking nut and to rotate the
adjusting nut anti-clockwise to raise the height of the door. Once the doors
are aligned, then tighten the locking nut by rotating it anti-clockwise.
When the fridge door is high:
Open the door, use a wrench to rotate the adjusting nut clockwise to lower
the height of the door. Once the doors are aligned, then tighten the locking
nut by rotating it anti-clockwise.
Charging the Light
Any replacement or maintenance of the LED lamps is intended to be made by
the manufacturer, its service agent or similar qualified person.
List of tools to be
provided by the user
wrench
