128
SPECIFICATIONS
* Based on EU Directive 76/432/EC
SPORTSMAN 850 XP / 850 XP EPS
Maximum Weight Capacity 575 lbs. (261 kg)
Dry Weight 759 lbs. (344.3 kg) (XP)
767 lbs. (347.9 kg) (XP EPS)
Fuel Capacity 5.25 gal. (20 l)
Engine Oil Capacity 2 qts. (1.9 l)
Coolant Capacity 2 qts. (1.9 l)
Rear Gearcase Oil Capacity 7.1 oz. (210 ml)
Demand Drive Fluid Capacity 9.3 oz. (275 ml)
Transmission Oil Capacity 32 oz. (950 ml)
Front Rack/Storage Box Capacity 120 lbs. (54 kg)
Rear Rack Capacity 240 lbs. (109 kg)
Receiver Hitch Tongue Capacity 150 lbs. (68 kg) (Rear rack load and tongue
weight not to exceed 240 lbs. /109 kg)
Hitch Towing Rating 1500 lbs. (680.4 kg)
Unbraked Trailer Towing
Capacity*
1914 lbs. (868 kg)
Overall Length 83.25 in. (211 cm)
Overall Width 47.6 in. (121 cm)
Overall Height 50.75 in. (129 cm)
Wheelbase 53 in. (134.6 cm)
Ground Clearance 11.6 in. (29.5 cm)
Minimum Turning Radius 84 in. (213 cm) unloaded
Engine EHO850LE
Displacement 850 cc
Bore x Stroke 87 x 71.5
Alternator Output 475w @1200 RPM/Peak 630w
Compression Ratio 11:1
Starting System Electric
Ignition System Electronic Fuel Injection
Idle RPM 1200 +/- 100
Ignition Timing 6 +/- 5 BTDC @ 1200 RPM, Engine warm
Spark Plug Type / Gap Champion REA8MCX / .035 in. (0.9 mm)
Lubrication System Wet Sump
Driving System Type Automatic PVT (POLARIS Variable Transmis-
sion)
Front Suspension Dual a-arm with 9.2" (23 cm) travel
Rear Suspension Progressive rate with 10.2" (26 cm) travel
