OIL CHECK
Always check the oil when the engine is cold. If the engine is hot when the oil is
checked, the level will appear to be overfull.
CAUTION
Always remove all cargo from the cargo box before lifting the box to access
engine components.
Access the oil fill cap, dipstick and filter under the cargo box.
1. Remove all cargo from the cargo box. See page 62.
2. Position the vehicle on a level surface.
3. Place the transmission in PARK.
4. Stop the engine.
5. Stand clear and pull up on the cargo box release lever. Lift the front of the
cargo box.
6. Remove the dipstick. Wipe it dry with a clean cloth.
7. Reinstall the dipstick completely. Remove the dipstick
q
and check the oil
level.
8. Remove the oil fill cap
w
to add the recommended oil as needed. Maintain
the oil level between the minimum and maximum marks on the dipstick. Do
not overfill.
9. Reinstall the fill cap . Reinstall the dipstick.
10.Lower the cargo box and push down securely to latch.
73
MAINTENANCE
