BATTERY
WARNING
Improperly connecting or disconnecting battery cables can result in an
explosion and cause serious injury or death. When removing the battery,
always disconnect the negative (black) cable first. When reinstalling the
battery, always connect the negative (black) cable last.
Your vehicle has a low-maintenance battery. Always keep battery terminals and
connections free of corrosion. If cleaning is necessary, remove the corrosion
with a stiff wire brush. Wash with a solution of one tablespoon baking soda and
one cup water. Rinse well with tap water and dry off with clean shop towels. Coat
the terminals with dielectric grease or petroleum jelly.
BATTERY REMOVAL
The battery is located under the driver’s seat on 2 passenger vehicles. On 4
passenger vehicles, the battery is under the left rear passenger seat.
1. Park the vehicle on a flat, level surface.
2. Ensure the vehicle is in PARK.
3. Turn the key switch to OFF and remove the key.
4. To access the battery, remove the seat. See Seat removal.
5. Remove the battery access panel.
6. Loosen the black (negative) battery cable fastener. Remove the cable from
the battery and move the cable away from the battery terminal.
7. Loosen the red (positive) battery cable fastener. Remove the cable from the
battery and move the cable away from the battery terminal.
8. Remove the battery hold-down strap.
9. Lift the battery out of the vehicle.
BATTERY INSTALLATION
Using a new battery that has not been fully charged can damage the battery and
result in a shorter life. It can also hinder vehicle performance. Follow the battery
charging instructions in the AGM Battery Maintenance and Charging section
before installing the battery.
1. Ensure that the battery is fully charged.
2. Place the battery in the battery holder.
3. Coat the terminals with dielectric grease or petroleum jelly.
4. Secure the battery hold-down strap.
97
MAINTENANCE
