CLUTCHING CHART
CLUTCH SETTINGS
ALTITUDE
meters (feet)
DRIVE CLUTCH DRIVEN CLUTCH
QUICK DRIVE
Gearing / Pitch
Shift
Weight
Clutch
Spring
Clutch
Spring
Driven
Helix
2.75 in
Track
3.0 in
Track
0-1500 (0-5000)* 14-76
(1327226)
BLK
165-310
(7045965)
BLK/PUR-
P
160-240
(7043363)
46S
(5144853)
22:43
69 Pitch
1500-3900
(5000-13,000)**
22:50
73 Pitch
Shaded cells indicate North American and INTL stock settings. Use 2 gram lighter
shift weights when operating in temperatures above 40° F (5° C).
* = North American and INTL Low-Elevation Stock Setting
** = North American and INTL High-Elevation Stock Setting
Drive Clutch Bolt Torque: 110 ft-lbs (149 N·m). Re-torque after running engine.
