DIAGNOSTIC TROUBLE CODES (DTCS) – MATRYX
SPN = SUSPECT PARAMETER NUMBER / FMI = FAILURE MODE INDICATOR
TROUBLE CODE SPN FMI
P-COD-
E
CONDITION
caused by Damaged Wiring/Connections,
a Faulty Ambient Pressure Sensor or
ECU.
Barometric Sensor
Circuit Voltage Low
108 4 P2228 This Trouble Code Sets if the Barometric
Pressure Sensor Signal Circuit is Shorted
to Ground. Can be caused by Damaged
Wiring/Connections, a Faulty Ambient
Pressure Sensor or ECU.
Engine
Temperature
Over-Temp
Shutdown
110 0 P1217 This Trouble Code sets if the Engine
Temperature indicates a Critical Over
Temperature Condition and the engine is
running in a limp-home mode to prevent
damage. Can be caused by any failure
that would cause the engine to overheat.
Engine
Temperature
Sensor Circuit
Voltage High
110 3 P0118 This Trouble Code sets if the Engine
Coolant Temperature Sensor Signal is
above 4.8 Volts. Can be caused by
Damaged Wiring, a faulty Coolant
Temperature Sensor or ECU /
Connections.
Engine
Temperature
Sensor Circuit
Voltage Low
110 4 P0117 This Trouble Code sets if the Engine
Coolant Temperature Sensor Signal is
below 0.1 Volts. Can be caused by
Damaged Wiring, a faulty Coolant
Temperature Sensor or ECU /
Connections.
Engine
Temperature
Abnormal Rate of
Change
110 10 P0119 This Trouble Code sets if the Engine
Coolant Temperature Sensor Signal is
erratic. Can be caused by Damaged
Wiring, a faulty Coolant Temperature
Sensor or ECU / Connections.
Engine
Over-temperature
Fault
110 16 P0217 This Trouble Code sets if the Engine
Temperature indicates a Severe Over
Temperature Condition. Can be caused by
any failure that would cause the engine to
overheat. This Trouble Code Does Not
indicate a problem with the Engine
Temperature Sensor.
Fuel Rail Pressure
Sensor Voltage
High
157 3 P0193 This trouble code sets if the Fuel Pressure
Sensor Voltage is above 4.85V. Can be
caused by Damaged Wiring, a faulty Fuel
Pressure Sensor or ECU / Connections.
192
DIAGNOSTIC TROUBLE CODES (DTC)
