DIAGNOSTIC TROUBLE CODES (DTCS) – MATRYX
SPN = SUSPECT PARAMETER NUMBER / FMI = FAILURE MODE INDICATOR
TROUBLE CODE SPN FMI
P-COD-
E
CONDITION
Ignition Coil 1
(MAG) Driver
Circuit Open
1268 5 P1351 This Trouble Code Sets if Ignition Coil 1
(MAG) Driver Circuit is Open. Can be
caused by Damaged Wiring/Connections,
a Faulty MAG Ignition Coil or ECU.
Ignition Coil 2
(PTO) Driver Circuit
Open
1269 5 P1352 This Trouble Code Sets if Ignition Coil 2
(PTO) Driver Circuit is Open. Can be
caused by Damaged Wiring/Connections,
a Faulty PTO Ignition Coil or ECU.
Max. Detonation
Correction Limit
Reached, MAG
Cylinder
1352 0 P1336 This Trouble Code Sets if the Engine
Controller Reaches the Maximum
Detonation Control Limit by Fuel
Correction on the Mag Cylinder Can be
caused by Incorrect Fuel (low octane or
Ethanol content) or Low Fuel Pressure.
Cylinder 1 (MAG)
Knock Level Critical
1352 16 P2336 This Trouble Code Sets if Cylinder 1
(MAG) Knock Sensor reaches a Critical
Level. Can be caused by Excessive Knock
(Fuel Problems), a Lean Running
Condition or Engine Mechanical
Problems.
Max. Detonation
Correction Limit
Reached, PTO
Cylinder
1353 0 P1337 This Trouble Code Sets if the Engine
Controller Reaches the Maximum
Detonation Control Limit by Fuel
Correction on the PTO Cylinder. Can be
caused by Incorrect Fuel (low octane or
Ethanol content) or Low Fuel Pressure.
Cylinder 2 (PTO)
Knock Level Critical
1353 16 P2337 This Trouble Code Sets if Cylinder 2
(PTO) Knock Sensor reaches a Critical
Level. Can be caused by Excessive Knock
(Fuel Problems), a Lean Running
Condition or Engine Mechanical
Problems.
Sensor Supply
Voltage 1 Low
3509 4 P06B1 This Trouble Code sets if the Sensor
Supply 1 Voltage is below an acceptable
limit (approx. 4.50 Volts). Can be caused
by Damaged Wiring or Faulty/Shorted
Sensors.
Sensor Supply
Voltage 2 Low
3510 4 P06B4 This Trouble Code sets if the Sensor
Supply 2 Voltage is below an acceptable
limit (approx. 4.50 Volts). Can be caused
by Damaged Wiring or Faulty/Shorted
Sensors.
195
DIAGNOSTIC TROUBLE CODES (DTC)
