DIAGNOSTIC TROUBLE CODES (DTCS) – MATRYX
SPN = SUSPECT PARAMETER NUMBER / FMI = FAILURE MODE INDICATOR
TROUBLE CODE SPN FMI
P-COD-
E
CONDITION
(2) Verify smooth valve operation by
operating the cable by hand through its full
travel, (3) Relearn EVIf no problem.
Exhaust Valve
Position Out of
Range (Closed)
520327 31 P140C This Trouble Code sets if: Valve DOWN
position voltage out of range. Check the
following: If occasional, this fault is nothing
to be concerned about If persistent:
Measure cable travel length and Verify
smooth valve operation.
Riding With Brakes
On Moderately
Severe
520555 31 C2418 This Trouble Code Sets if the Sled has
been driven with the brakes applied
continuously for 10 seconds, 4500 RPM.
Riding With Brakes
On Most Severe
520556 31 C2419 This Trouble Code Sets if the Sled has
been driven with the brakes applied
continuously for 20 seconds , 4500 RPM.
Regulator Near
Thermal Shutdown
520660 31 P161B This Trouble Code Sets if the Regulator is
near the thermal shutdown point. Can be
caused by excessive power consumption
or insufficient cooling air flow.
Batch Fire
Detection
523959 31 P3022 This Trouble Code Sets if the engine is in
"Batch Fire Mode". Can be caused by
Damaged Wiring, a faulty Crankshaft
Sensor or ECU / Connections.
Exhaust Valve
Actuator Short
Circuit
523958 3 P3023 This trouble code sets if the ECU detects
a short in the EV Actuator Drive circuit.
Can be caused by Damaged Wiring,
Faulty EV Actuator, or ECU / Connections.
Inspect EV Actuator Drive wires.
(White/Green & White/Blue).
Exhaust Valve
Actuator Open
Circuit
523958 5 P3024 This trouble code sets if the ECU detects
low current or an open EV Actuator Drive
circuit. Can be caused by Damaged
Wiring, Faulty EV Actuator, or ECU /
Connections. Inspect EV Actuator Drive
wires. (White/Green & White/Blue).
Exhaust Valve
Actuator Open
Circuit
523958 4 P3025 This trouble code sets if the ECU detects
low current or an open EV Actuator Drive
circuit. Can be caused by Damaged
Wiring, Faulty EV Actuator, or ECU /
Connections. Inspect EV Actuator Drive
wires. (White/Green & White/Blue).
201
DIAGNOSTIC TROUBLE CODES (DTC)
