DIAGNOSTIC TROUBLE CODES (DTCS) – LEFT
HAND CONTROLS
MATRYX LEFT HAND CONTROLS – DIAGNOSTIC TROUBLE CODES (DTCS)
SPN = SUSPECT PARAMETER NUMBER / FMI = FAILURE MODE INDICATOR
SPN FMI
P-CO-
DE
DESCRIPTION FAULT SETTING
FAULT
HEALING
516360
0 C1106 Left Grip Heater
Driver Over Temp
The temperature at
left grip heater driver
is greater than 60
DegC for 5 seconds
The temperature
at left grip heater
driver is less
than 60 DegC for
5 seconds
5 C1107 Left Grip Heater
Driver Under
Current
The current at left
grip heater driver is
is less than 1A for 5
seconds
The current at
left grip heater
driver is is
greater than
1.5A for 5
seconds
6 C1108 Left Grip Heater
Driver Over
Current
The current at left
grip heater driver is
is greater than 7A for
5 seconds
The current at
left grip heater
driver is is less
than 6A for 5
seconds
31 C1109 Left Grip Heater
Driver Internal
Short
An internal short has
been detected at the
left grip heater driver.
This would result in a
100% duty cycle
output when not
expected.
An internal short
is not detected at
the left grip
heater driver.
516361
0 C110A Right Grip Heater
Driver Over Temp
The temperature at
right grip heater
driver is greater than
60 DegC for 5
seconds
The temperature
at right grip
heater driver is
less than 60
DegC for 5
seconds
5 C110B Right Grip Heater
Driver Under
Current
The current at right
grip heater driver is
is less than 1A for 5
seconds
The current at
right grip heater
driver is is
greater than
1.5A for 5
seconds
6 C110C Right Grip Heater
Driver Over
Current
The current at right
grip heater driver is
is greater than 7A for
5 seconds
The current at
right grip heater
driver is is less
than 6A for 5
seconds
209
DIAGNOSTIC TROUBLE CODES (DTC)
