E-VES DIAGNOSTIC TROUBLE CODES (DTCS)
E-VES DIAGNOSTIC TROUBLE CODES (DTCS)
SPN = SUSPECT PARAMETER NUMBER / FMI = FAILURE MODE INDICATOR
P-CODE SPN FMI
DESCRIP-
TION
LIKELY CAUSE
(S)
ECU
RESPONSE
PRIMARY
COURSE OF
ACTION
P1400
5203-
24
3
Diagnostic
voltage too
high
Diagnostic line
(Pink / Black in
harness, Brown
on signal
converter) short
to +12V
Actuator power
(Red / Black)
removed
ECU will not
allow UP
state.
Fuel
according to
actual
position
Inspect PWM
converter wiring for
chaffing / broken
wires
Ensure no loose
pins in converter
connector
Replace signal
converter if no wire
/ connector issues
are found
P1401 5
Diagnostic
circuit open /
grounded
Diagnostic line
(Pink / Black in
harness, Brown
on signal
converter) open
circuit
Command wire
(Dark Blue /
White) short to
GND
Command wire
(Dark Blue /
White) open
Actuator power
(Red / Black)
removed
P1402 13 Learn failure
Feedback
voltage out of
range during
learn
ECU will force
to DOWN
state and fuel
accordingly
Ensure battery is
sufficient for
relearn (maintains
11.5 volts during
the entire
procedure)
Ensure Signal
converter and / or
actuator are not
disconnected
Ensure EV relay is
connected,
operational (clicks)
and has no
damage to terminal
wiring
Check for broken
EV cable
211
DIAGNOSTIC TROUBLE CODES (DTC)
