MAINTENANCE AND LUBRICATION
Lights
Ta illig ht/Brakelig ht Lamp Replacement
If the taillight/brakelight does not work the lamp may need to be
replaced.
1. Remove the taillight lens
cover mounting screws (1).
2. Remove the lens
cover and set aside
for reassembly.
3. Remove the lamp (2).
4. Apply dielectric grease to the socket and install a new lamp.
5. Test the taillight/brakelight for proper operation.
6. Reinstall the lens cover.
1
2
