158
Maintenance
Tail Light Lamp Replacement
If the brakelight doesn't work, the lamp may
need to be replaced.
1. Remove the two screws securing the lens
cover. Remove the lens cover.
2. Remove the lamp and replace it with a
new recommended lamp.
3. Test the light for proper operation.
4. Reinstall the lens cover.
Screws
Cover
