Spindle Nut
Front
70 ft. lbs. (95
Nm)
Hub Retaining Nut
Center and Rear
110 ft. lbs. (150
Nm)
WHEEL REMOVAL
1. Position the vehicle on a level surface.
2. Apply the brakes. Set the park brake. Turn the key off.
3. Loosen the wheel nuts slightly.
4. Elevate the side of the vehicle by placing a suitable stand under the frame.
5. Remove the wheel nuts and washers. Remove the wheel.
WHEEL INSTALLATION
1. Set the park brake.
2. Place the wheel on the hub with the valve stem toward the outside and
rotation arrows on the tire pointing toward forward rotation.
WARNING
Improperly installed wheels can adversely affect tire wear and vehicle
handling, which can result in serious injury or death. Always ensure that all
nuts are torqued to specification. Do not service axle nuts that have a cotter pin
installed. Your dealer can assist.
3. Attach the wheel nuts and washers and finger-tighten.
4. Carefully lower the vehicle to the ground.
5. Torque the wheel nuts to specification.
89
MAINTENANCE
