3. Remove the bolt and nut securing the bracket
w
to the passenger side top
radiator mount.
4. Remove the air filter
r
.
5. Inspect the air filter. Shake the filter to remove excess dirt. If the filter remains
caked with dirt, replace the filter with a new filter.
6. If replacing the air filter, remove the nut
e
and bracket, and reinstall the
bracket and nut on the new air filter.
TORQUE
Nut: 3.3-3.75 ft-lbs (4.5-5.1 Nm)
7. Reinstall the air filter, or install a new air filter, with the clamp.
NOTICE
Operating the vehicle without the air filter installed can result in serious engine
damage, which could result in an accident and injury to the operator and
others. Always make sure the air filter is installed.
8. Install the bolt and nut, securing the bracket to the passenger side top
radiator mount.
TORQUE
Bolt: 7-9 ft-lbs (9.5-12.2 Nm)
82
MAINTENANCE
