9.20
9924864 - 2012-2014 SPORTSMAN 800 / 6X6
© Copyright 2013 Polaris Sales Inc.
4. Compress the mounting bracket and make sure the
dust seals are fully seated. Install the brake pads.
Clean the disc and pads with brake parts cleaner or
denatured alcohol to remove any dirt, oil or grease.
Installation
1. Install caliper on hub strut, and torque mounting bolts
to specification.
Brake Caliper Mounting Bolt:
18 ft-lbs (24 Nm)
2. Install brake line and torque the banjo bolt to
specification.
Brake Line Banjo Bolt:
15 ft-lbs (21 Nm)
3. Install the adjuster screw and turn until stationary
pad contacts disc, then back off 1/2 turn.
4. Perform brake bleeding procedure as outlined earlier
in this chapter.
5. Install wheels and torque wheel nuts to specification.
Refer to Chapter 2.
BRAKES
