EFI CODE FAILURE DESCRIPTION
21
Loss of Synchronization
22
TPS: Open or Short Circuit to Ground
22
TPS: Short Circuit to Battery
23 RAM Error: Defective ECU
25
Transmission Input - Invalid Gear
26
Vehicle Speed Sensor - Implausible
41
Intake Air Temp Sensor: Open or Short Circuit to +Sensor Voltage
41
Intake Air Temp Sensor: Short Circuit to Ground
42
Engine Temp Sensor Circuit: Short to Ground
42
Engine Temp Sensor Circuit: Open or Short to Battery
45
Barometric Pressure Sensor: Circuit Low Input
46
Barometric Pressure Sensor: Circuit High Input
51
Injector 1: Open Load
51
Injector 1: Short Circuit to Ground
51
Injector 1: Short Circuit to Battery
52
Injector 2: Open Load
52
Injector 2: Short Circuit to Ground
52
Injector 2: Short Circuit to Battery
54
Engine Temp Lamp: Open Load
54
Engine Temp Lamp: Short Circuit to Ground
54
Engine Temp Lamp: Short Circuit to Battery
55
Diagnostic Lamp: Open Load
55
Diagnostic Lamp: Short Circuit to Ground
55
Diagnostic Lamp: Short Circuit to Battery
56
Pump Relay: Open Load
56
Pump Relay: Short Circuit to Ground
56
Pump Relay: Short Circuit to Battery
58
Cooling Fan: Open Load
58
Cooling Fan: Short Circuit to Ground
58
Cooling Fan: Short Circuit to Battery
61 END of Check
