Polaroid FLM-2632 Service Manual

10
HDMI
Format
DVI 1.0
Level/Impedance
0.5~3.0Vp-p/100 Ohm (Differential),50 Ohm (Single ending)
TMDS Mode
Single Link
Frequency Fh = 31~80 kHz
Fv = 56~76 Hz
Maximum Pixel Clock
135 MHz
DDC 1/2B
Compliant with Revision 1.0
Connector
HDMI x 1
Analog HD15 PC Signal (RGB)
Format
R, G, B Analog
Level/Impedance
0.7Vp-p / 75Ω
DDC 1/2B
Compliant with Revision 1.0
Sync H/V separate
3V TTL level / 1kΩ
Frequency Fh = 31~80 kHz
Fv = 56~76 Hz
Maximum Pixel Clock
135 Mhz
Connector
Mini D-Sub 15 pin (female) x 1
Video (Composite) CVBS Signal
Format
NTSC, 4.43NTSC, PAL_M, PAL(B,G,H,D,N), SECAM
Level / Impedance
1.0Vp-p / 75Ω
S-Video (Y/C) Signal
Format
Y, C
Level / Impedance Y: 1.0Vp-p / 75Ω
C: ± 286 mV/ 75Ω
Analog HD15 Video Signal (YPbPr/YCbCr)
Format
Y, Pb, Pr or Y, Cb, Cr
Level / Impedance Y: 1.0Vp-p / 75Ω
Pb/Cb, Pr/Cr: 0.7 ± 0.035Vp-p / 75Ω
HDMI Timing
STANDARD RESOLUTION
V FREQ
Hz
H FREQ
kHz
CLK
MHz
ATSC, 480i 720x480 60 15.7 27
ATSC, 480p 720x480 60 31.5 27
ATSC, 1080i 1920x1080 60 33.7 74.2
ATSC, 720p 1280x720 60 45.0 74.2
ATSC, 576i 720x576 50 15.6 27
