12
Power Source
AC100 – 240 V, 60/50 Hz
Sound Output 10W X2, 8 Ohm.
Signal Connector Pin Assignment
Pin Assignment Pin Assignment Pin
A
ssi
g
nmen
t
1. Red 6. Red Ground 11. Ground
2. Green 7. Green Gro und 12. SDA
3. Blue 8. Blue Ground 13. Horizontal S
y
4. Ground 9. Not Connected 14.
Vertical
Sync.
5. Self Test 10. Sync. Ground 15. SCL
