25
Procedures:
1. Remove screws (PIC1) in the sequence of 1, A.
2. Remove screws (PIC1) in sequence of 2, 3, 4, B, C, D
3. Proceed to next step
Procedures:
1. Remove screws which fasten rear cabinet to front frame (PIC1) in the
following sequence:
AÆBÆCÆDÆEÆF then 1Æ2Æ3Æ4Æ5
2. Remove rear cabinet cover. Only the rear cabinet cover will come off.
3. Proceed to next step
To Next Page
