29
Procedures:
1. Remove from the D-sub board Speaker wire, Front/Side Control Button wire, and A/V
wire connectors (PIC1)
2. Remove the black tape from the Speaker wire and Ceramic ring (PIC2)
3. Replace black tape during assembly.
4. Proceed to next step
Front/Side Control Button wire
