Polk Mono Monitor XT10 - Polk Audio Subwoofer Features; Back Panel Controls Overview

English
MAXMIN
VOLUME
Monitor XT10 subwoofer
LOW PASS LINE IN
L/LFE
R
100
40
160
(LFE)
AC IN
2022-07-25
2022-06-07 Updated phase and power switch position
2022-07-25 Removed fuse symbol
HBP4830
Full Size
Josue Baltezar
White
Date
Drawing #
Scale
Prepared by
Color
Monitor XT10 Amp Back Panel NA
DateRevision Description
Pad printingProcess
Finish
Notes
1. Low pass filter knob
2. Phase switch
3. LED power indicator
4. On/auto/off power switch
5. Volume control knob
6. Line in (LFE = White RCA)
7. AC power inlet
Subwoofer back-panel controls
Subwoofer features
1
2 4
3
5 6
7
