ME60BT Bluetooth Amplifier 6
————————————————————————————
PO Box 409 Hanover, MD TEL (410) 761-4000 www.polyplanar.com
warranty.
Whenever possible, use cable ties, mounting clamps and similar wiring
aids. Adding stress relief loop to wiring is also advisable to prevent
straining or breakage.
If after reading the directions you feel uncomfortable about installing the
unit, or not equipped or competent to do so, you should have this installed
by a professional installer
Connect the white and grey loudspeaker wires to 1 or 2 pairs of
loudspeakers. Pay close attention to polarity (black stripe = negative)
Connect the green and purple loudspeaker wires to 1 or 2 pairs of
loudspeakers or to a subwoofer if the low pass filter switch is depressed
Input connections:
