poly-planar ME60BT - Mounting Surface

ME60BT Bluetooth Amplifier 3
————————————————————————————
PO Box 409 Hanover, MD TEL (410) 761-4000 www.polyplanar.com
poly-planar
Marine Audio Systems
Mounting the Keypad Control:
1) Choose a mounting location with a flat surface the size of the keypad
control body
2) There must be at least 2.56” (65mm) of clearance behind the mounting
area
3) Drill a 2.76” (70mm) hole making sure that there is nothing behind the
surface that could be damaged.
4) Run all cables, make connections, and test the entire system.
Drill
KEYPAD
MOUNTING SURFACE
MOUNTING NUT
2.56” (65mm)
(2.76” (70mm))
