GP 44
Spare Parts - 52 -
PART LIST
M2 MOTOR FIG. M2-02
Key Part-No Description Key Part-No Description
1 E21060 M2 Motor 100V 150W EF0P-KP-4P 9 P18002 Flat Washer
2 B08325 Hexagon Bolt M6×25 10 N01092 Rubber
3 B27300 Spring Washer M6 11 T00114 Chain L46
4 B26300 Flat Washer M6 12
5 B21300 Nut M6 13
6 M06010 Key 5×5×25 14
7 B10206 Set Bolt M5×6 15
8 T02025 Sprocket RS25 T20 16
