GP 44
Spare Parts - 53 -
PART LIST
PANEL FIG. PANEL-14
Key Part-No Description Key Part-No Description
1 P30234 Front Panel 21 B26300 Flat Washer M6
2 P30235 Front Door 22 B27000 Spring Washer M3
3 N00003 Door Knob 23 B17000 Nut M3
4 P30762 Right Panel 24 B00210 Pan Head Screw M5×10
5 N00070 Clear Cover 25 B27200 Spring Washer M5
6 P30232 Rear Panel 26 P00023 Safety Switch Bracket
7 P30236 Left Panel 27 B17100 Nut M4
8 P30231 Panel Cover 28 B27100 Spring Washer M4
9 A00342 Relay Box 29 B26100 Flat Washer M4
10 P30410 Relay Box Cover 30 E06018 Micro Switch BA-2RV22-T4-J
11 B07106B Bolt M4×6 31 P03009 Switch Plate
12 B40208 Button Bolt M5×8 32 B00130 Pan Head Screw M4×30
13 B27300 Spring Washer M6 33
14 B17300 Nut M6 34
15 B04315 Cap Screw M6×15 35
16 B40212 Button Bolt M5×12 36
17 B00018 Pan Head Screw M3×18 37
18 B26000 Flat Washer M3 38
19 R00001 Magnet 100A-1 39
20 B17400 Nut M8 40
To Next Page
