GP44 Semi-Automatic Strapping Machine
OPERATION -41-
ADJUSTMENT OF ELECTRO MAGNETIC BRAKE ON THE MOTOR
1. There is brake on the motor and conveyor motor.
If brake on the cam motor does not work correctly, camshaft does not stopping in the home position and
the right gripper being up.
If brake on the conveyor motor does not work correctly, a parcel does not always
stop at the strapping position.
2. The clearance between each brake must be 0.12~0.20mm.
In order to adjust the clearance, loosen set bolt and move the outer brake.
