Polychem GP44 - Part List: Rear of Machine (Fig. GP44-09)

GP 44
Spare Parts - 4 -
PART LIST REAR OF MACHINE FIG. GP44-09
Key Part-No Description Key Part-No Description
1 A03039 Frame 12 See→ FIG. A-15-001
2 R04003 Caster (SG-75C) 13
3 See→ FIG. PANEL-14 14
4 See→ FIG. PANEL-14 15
5 E21049 Blower (109S005) 16
6 E98011 Lower Cover 17
7 See→ FIG. PANEL-14 18
8 See→ FIG. A-19-002 19
9 See→ FIG. A-19-002 20
10 See→ FIG. A-15-001 21
11 See→ FIG. A-15-001 22
.
