Polychem GP44 - Page 53

GP 44
Spare Parts - 5 -
PART LIST FRONT OF MACHINE FIG. GP44-10
Key Part-No Description Key Part-No Description
1 A03039 Frame 12 See→ FIG. A-15-014
2 R04007 Caster With Brake (SG-75CS) 13 See→ FIG. A-15-014
3 See→ FIG. PANEL-14 14 See→ FIG. ELEC-017
4 See→ FIG. PANEL-14 15
5 See→ FIG. PANEL-14 16
6 See→ FIG. A-1-1 17
7 See→ FIG. D-1P 18
8 See→ FIG. RIGHT-02 19
9 See→ FIG. A-19-003 20
10 See→ FIG. A-19-003 21
11 See→ FIG. A-15-014 22
