Polychem GP44 - Page 54

GP 44
Spare Parts - 6 -
PART LIST REAR OF MACHINE FIG. GP44-11
Key Part-No Description Key Part-No Description
1 A03039 Frame 12 See→ FIG. A-15-014
2 R04003 Caster (SG-75C) 13
3 See→ FIG. PANEL-14 14
4 See→ FIG. PANEL-14 15
5 E21049 Blower (109S005) 16
6 E98011 Blower Cover 17
7 See→ FIG. A-15-014 18
8 See→ FIG. A-19-003 19
9 See→ FIG. A-19-003 20
10 See→ FIG. A-15-014 21
11 See→ FIG. A-15-014 22
