GP 44
Spare Parts - 9 -
PART LIST POOL BOX FIG. A-7-2-H
The different parts for strap size and the arch size.
Key Part-No Description Key Part-No Description Key Part-No Description
1 P30221 Pool Box 31 L24012 Pool Switch Supporting
Metal
18 P03178 Stopper for Loading Guide (All size
except 14mm strap)
2 B04008 Cap Screw M3×8 32 B06315 Flat Head Screw M6×15 18 P03357 Stopper for Loading Guide (14mm strap
exclusive)
3 B27000 Spring Washer M3 33 M00070 Upper Guide
4 B27300 Spring Washer M6 34 * * 34 C03074 Strap Guide for 5mm
5 B17300 Nut M6 35 * * 34 C03073 Strap Guide for 6mm
6 A00147 Solenoid Bracket 36 B31010 Roll Pin 3×10 34 C03072 Strap Guide for 7mm
7 B04110 Cap Screw M4×10 37 M00048 Vertical Guide 34 C03071 Strap Guide for 9.5mm
8 B27100 Spring Washer M4 38 B00020 Pan Head Screw M3×20 34 C03070 Strap Guide for 12mm
9 B26100 Flat Washer M4 39 P00115 Proximity Switch Base 34 C03132 Strap Guide for 14mm
10 E30006 Solenoid MD191 DC100V 40 B04010 Cap Screw M4×10 34 C03069 Strap Guide for 15mm
11 S06022 Spring for Plunger 41 E06025 Proximity Switch GL-12F
12 L12073 Plunger for Solenoid MD191 42 35 B04020 Cap Screw M3×20 (5-6mm Strap)
13 L00055 Spacer 43 35 B04025 Cap Screw M3×25 (7-9.5mm Strap)
14 P00121 Loading Guide 44 35 B04030 Cap Screw M3×30 (12-15mm Strap)
15 B04330 Cap Screw M6×30 45
16 B26300 Flat Washer M6 46
17 B06106 Flat Head Screw M4×6 47
18 * * 48
19 B17000 Nut M3 49
20 B26000 Flat Washer M3 50
21 L00012 Spacer for Magnet 51
22 R00000 Magnet for Pool Box 52
23 P00085 Pooling Adjuster Base 53
24 B17100 Nut M4 54
25 P00144 Pooling Adjuster Bracket 55
26 B04112 Cap Screw M4×12 56
27 B04106 Cap Screw M4×6 57
28 S03059 Spring for Pool Box 58
29 B04018 Cap Screw M3×18 59
30 A00352 Detect lever 60 Drawing FIG. A-7-2-D
To Next Page
