GP 44
Spare Parts - 8 -
PART LIST REEL ASSY. FIG. A-1-1P1
Key Part-No Description Key Part-No Description
1 N00033 Reel Shaft Nut 1 12 B10308 Set Bolt M6×8
2 N02000 Fiber Washer 13 A00234 Reel Support 8 inch
3 A00247 Reel Cover Front 13 A00248 Reel Support 9 inch
4 A00246 Reel Shaft 14 N01008 Rubber for Reel
5 M06006 Key 7×7×25
6 B10306 Set Bolt M6×6
7 L00008 Reel Shaft Collar
8 T04029 Ball Bearing 6005LLU
9 C00024 Reel Shaft Bearing Block
10 B27500 Spring Washer M10
11 B17500 Nut M10
To Next Page
