GP 44
Spare Parts - 26 -
PART LIST
ARCH COVER FIG. A-15-014
Key Part-No Description Key Part-No Description
1 P30237 Arch Cover B600
1 P30261 Arch Cover B800 5 P03189 Arch Plate
1 P30262 Arch Cover B1000
1 P30263 Arch Cover B1200 7 B27300 Spring Washer M6
2 P30264 Arch Cover C800 8 B17300 Nut M6
2 P30265 Arch Cover C1000 9 B04315 Cap Screw M6×15
2 P30266 Arch Cover C1200 10 B04310 Cap Screw M6×10
2 P30267 Arch Cover C1400 11
2 P30268 Arch Cover C1600 12 B07208 Screw M5×8
3 P30225 Arch Cover D600 13 B17200 Nut M5
3 P30269 Arch Cover D800 14 B07212 Screw M5×12
3 P30270 Arch Cover D1000 15 B27200 Spring Washer M5
3 P30271 Arch Cover D1200 16
4 P30238 Arch Cover A800 17
4 P30257 Arch Cover A1000 18
19
20
To Next Page
