GP 44
Spare Parts - 27 -
PART LIST
ARCH COVER FIG. A-15-001
Key Part-No Description Key Part-No Description
P30272 Arch Cover B400 6 B07212 Screw M5×12
1 P30305 Arch Cover B500 7 B27200 Spring Washer M5
1 P30237 Arch Cover B600 8 B17200 Nut M5
1 P30261 Arch Cover B800 9
1 P30262 Arch Cover B1000 10
1 P30263 Arch Cover B1200 11
2 P30226 Arch Cover C600 12
3 P30273 Arch Cover D400 13
3 P30304 Arch Cover D500 14
3 P30225 Arch Cover D600 15
3 P30269 Arch Cover D800
3 P30270 Arch Cover D1000
3 P30271 Arch Cover D1200
4 P03189 Arch Plate
5 B40208 Button Bolt M5×8
4
2
1
3
4
5
5
6
7
8
To Next Page
