Spare Parts - 46 -
PART LIST CLAMP ASSY. FIG. H11-011-H
The different parts for strap size and the arch size.
Key Part-No Description Key Part-No Description Key Part-No Description
1 B31012 Roll Pin φ3×12 31 9 M00355 First Clamp Guide (5mm strap)
2 B31212 Roll Pin φ5×12 32 9 M00006 First Clamp Guide (6,7mm strap)
3 T04015 Ball Bearing 635zzs 33 9 M00007 First Clamp Guide (8,9mm strap)
4 L12000 Compression Lower 34 9 C03019 First Clamp Guide (12,15mm strap)
5 S06046 Spring 35 9 C03077 First Clamp Guide (14mm strap)
6 P18041 Shim 36
7 B31018 Roll Pin φ3×18 37 11 C03134 First Clamp (5mm strap)
8 S03009 Compression Spring 38 11 C03049 First Clamp (6,7mm strap)
9 * 39 11 C03018 First Clamp (8,9,12mm strap)
10 B04010 Cap Screw M3×10 40 11 C03067 First Clamp (14mm strap)
11 * 41
12 * 42 12 M00088 Upper Guide (5mm strap)
13 B04008 Cap Screw M3×8 43 12 M00072 Upper Guide (6,7mm strap)
14 * * 44 12 M00073 Upper Guide (8,9mm strap)
15 * 45 12 M00074 Upper Guide (12mm strap)
16 * 46 12 M00075 Upper Guide (14mm strap)
17 P21004 Compression Cover 47 12 M00076 Upper Guide (15mm strap)
18 B04308 Cap Screw M6×8 48
19 B31112 Roll Pin φ4×12 49 14 S03004 Cutter Spring (5,14mm strap)
20 M00354 First Clamp Guide (5mm strap) 50 14 S03024 Cutter Spring (6,7,8,9,12mm Strap)
21 B02008 Flat Head Screw M3×8 (5mm strap) 51
22 52 15 C03014 Compression (5,6mm strap)
23 53 15 C03013 Compression (7,8,9mm strap)
24 54 15 C03012 Compression (12,14,15mm strap)
25 55
26 56 16 C03055 Second Clamp (5,6,7,8,9,12mm strap)
27 57 16 C03054 Second Clamp (14,15mm strap)
28 58
29 59
30 60 Drawing FIG. H11-011-D
To Next Page
