GP 44
Spare Parts - 50 -
PART LIST
CAM SWITCH FIG. H15-000
Key Part-No Description Key Part-No Description
1 B00110 Pan Head Screw M4×10 9
2 B27100 Spring Washer M4 10
3 P00133 Cam Switch Bracket 11
4 B31015 Roll Pin φ3×15 12
5 B17000 Nut M3 13
6 B27000 Spring Washer M3 14
7 E06025 Proximity Switch M GL-12F 15
8 B04012 Cap Screw M3×12 16
To Next Page
