Polycom HDX Ceiling Microphone Array Series

For suspended ceilings
12
Setting up the Polycom HDX Ceiling Microphone Array Series
1
2
a
2’ (.6 m)
Setting up the Polycom HDX Ceiling Microphone Array Extension Kit
for Polycom HDX Systems, SoundStructure C-Series Systems, and
TPX HD 306M Systems
25’ (7.6 m) plenum
crossover
(use between two
electronics enclosures)
Note: If you are creating your own cables, refer to the Integrator’s Reference Manual for Polycom HDX Systems
for cable pin-outs. You can find this document at www.polycom.com/videodocumentation.
