1. System Synopsis
z The PC-1074 is designed for high-security access control and real-time
monitoring environments from medium size to complex multi-site installations.
z It is an independent processing 4 doors access control package with metal
enclosure, backup battery charger as an efficient space saving design.
z Suitable for applications with up to 64,000 users across a modular 1024 doors,
allowing maximum flexibility for securing a growing enterprise. Each unit
supports 8 Wiegands or RS-485 ports for entry & exit control.
z The system support Bar Code, Magnetic Stripe, Biometric and Smart Card
Readers thru. Wiegand or ABA interface.
z Designed with 4 DI (digital input) and 4 DO (digital outputs) for light, air
conditioning, surveillance, fire prevention or urgent rescuing system control.
2. System Features
z Online Network with on board selectable RS-485/RS-232/RS-422 and optional
TCP/IP Ethernet.
z Up to 15,000 cards with 32,000 events. Optional 64,000 cards with 64,000
events.
z Multi technology of badges include proximity, smart card, biometric, hand free
active card, mag. cards, etc.
z 8 wiegand readers for 4 doors. expandable to 16 wiegand readers for 8 doors.
Optional 8 or 16 RS-485 readers for 8 doors by 2nd RS-485 port.
z 4 digital inputs and 4 digital outputs with expansible 24/48/64 relays output for
floors control.
z Global (4 or expandable 8 doors) or single doors APB without PC autonomous
decision at local level without degradation and removable connectors
z Optional baud rate from 2,400 to 38,400 with optional encryption for
communication security.
3. System Specifications
Metal Enclosure Dimensions
Board Dimensions
273(L) x 218(W) x 80(H) mm
160(L) x 115(W) x 24.5(H) mm (PC-1074B)
Weight PCB & Metal Enclosure 4.7kg ± 5%
PCB only 480g ± 5%(PC-1074B)
Power supply DC 15V ±10%, 1.7A
UPS 7.2A/H
Transmission rate 9,600 bps, N,8,1
Serial interface RS-485 <RS-232C, RS-422, TCP/IP(Option)>
Events 32,000 standard, up to 64,000
Card capacity 15,000 standard, up to 64,000
External reader Wiegand 26, 34bits reader
Time zone 8 personal time zones, 8 time zones for auto
operation mode
Memory 6 MB, EEPROM
Operation temperature
0℃ ~ 50℃
Humidity 5%~95%
