2-72
T-Top Sunshades
To install the T-top sunshades do the following:
1. Start with the panel marked DRIVER FRONT.
Unlatch the driver’s side T
-top, raise it halfway and
close the latch handle.
2. With the top raised and resting on the center roof
rail, slide the flat edge of the sunshade panel (with
the vinyl side to the glass) between the glass and
plastic trim, making sure the edge marked DRIVER
FRONT is pointing to the front of the vehicle.
3. Open the latch and close the T-top. Check to see if
there are any gaps showing. Unlatch the T
-top and
adjust the sunshade as required.
4. Once the sunshade is installed properly, you can
stick the Velcro
R
buttons on the glass for a proper
fit every time you install the sunshades. To do this,
first remove the T-top with the sunshade installed
and place it upside down on a table or bench.
Take care not to scratch the glass.
