Taillamps, Turn Signal, Sidemarker,
Stoplamps and Back-up Lamps
(Sedan)
A. Stoplamp/Taillamp/Turn Signal
B. Sidemarker Lamp
C. Back-up Lamp
To replace one of these bulbs:
1. Open the trunk. See Trunk on page 2-13 for more
information.
2. Remove the convenience net, if the vehicle has one.
3. Remove the wing nuts holding the trunk trim.
4. Remove the two nuts, which hold the taillamp
assembly, from inside the vehicle.
5. Remove the taillamp assembly.
6. Turn the bulb socket counterclockwise to remove.
7. Pull the bulb from the socket.
8. Install a new bulb.
9. Reverse Steps 2 through 7 to reinstall the taillamp
assembly.
5-55
