Pool Warehouse SUNRAY - Prepare Buttress Trenches

No Diving or Jumping. Observe all Safety Rules.
1-13
5. Add Corner Stakes
a. Prepareeightcornerstakes(D),(E),
(F)&(G),and(H),(I),(J)&(K)by
markingthecentrepoint ofeachstake
thesamewayasinstep4(c).
b. Drivetheeightcornerstakesintothe
ground.Drivethemdownushwith
thegroundsurface.Locateeachstake
exactlybyusingthemeasurements
foryourpoolinthechartbelow.Be
suretomeasureusingthecentrepoint
ofeachstake.
c. Tiestringsbetweenstakes(H)and(I)andbetween(J)and(K).
6. Prepare Buttress Trenches
a. Locatethersttrenchbymeasuring
the distance Mfromthecentreof
stake(H)tothecentreline ofthe
trench.Usethechartbelowtondthe
rightdistanceMforyourpool.
b. Placeastakeinthegroundonthe
edgeoftheclearedareaatdistance
M,underneaththestringaddedinstep
5(c).
Hint:
Insteadofwoodencor-
nerstakes,youcanuse
12"(30cm)spikes.
Pool Size Distance X Distance Y Distance W Distance Z
12' x 18' (3,66m x 5,49m) 72" (183cm) 80-1/2" (204cm) 96" (244cm) 102-1/2" (260cm)
12' x 24' (3,66m x 7,32m) 72" (183 cm) 101-3/4" (258cm) 96" (244cm) 120" (305cm)
15' x 24' (4,57m x 7,32m) 90" (229cm) 105" (267cm) 114" (290cm) 126-1/8" (320cm)
15' x 30' (4,57m x 9,14m) 90" (229cm) 127-1/4" (323cm) 114" (290cm) 145-1/4" (369cm)
18' x 33' (5,49m x 10,05m) 108" (274cm) 140-5/8" (357cm) 132" (335cm) 159-3/4" (406cm)
24
Pool Size Distance from Stake to Distance between
Trench Centreline M Trenches N
12' x 18' (3,66m x 5,49m) 36" (91cm) n/a
12' x 24' (3,66m x 7,32m) 24" (61 cm) 48" (122cm)
15' x 24' (4,57m x 7,32m) 30" (76cm) 48" (122cm)
15' x 30' (4,57m x 9,14m) 30-1/2" (77cm) 59-1/2" (151cm)
18' x 33' (5,49m x 10,05m) 30-1/2" (77cm) 59-1/2" (151cm)
23
